Vertical pallet CNC machining for diverse industrial applications.
| Feature | Range |
|---|---|
| Pallet Size | 1000mm x 1000mm to 1525mm x 1300mm |
| Max. Load on Pallet | 3,000kgs to 8,000kgs |
| X-Axis Travel | 1500mm to 2110mm |
| Y-Axis Travel | 1270mm to 1830mm |
| Z-Axis Travel | 1250mm to 1830mm |
The THX Series from Racer Machinery represents a significant leap forward in vertical pallet machining. This series boasts exceptional rigidity, power, and automation, making it ideal for high-production environments.
Choose from three models (THX 1000, THX 1250, THX 1600) to perfectly match your project’s size requirements. Each model offers a full 360° pallet index for efficient multi-sided machining, and generous travel ranges on all linear axes (X, Y, Z) provide exceptional machining flexibility.
Custom sizes available.
Looking for more details?
THX Series Machining Center Features
- Accuracy: The THX series boasts high levels of accuracy, with linear position accuracy of 0.005mm and repeatability of 0.002mm.
- Rotary Table: The machines are equipped with rotary tables that provide accuracy ranging from 3 arc sec to 7 arc sec/3.5 arc sec, ensuring precise machining of circular components.
- Control: All THX models feature Siemens ONE control, providing a user-friendly interface for machine operation.
- Rapid Speeds: The machines offer rapid speeds of 40m/min for efficient movement and positioning.
- Tool Storage: The machines offer a range of tool storage capacities from 60 to 240 tools, accommodating a variety of cutting tools.
Ideal Applications
Technical Data
THX Series
| Model | THX 1000 | THX 1250 | THX 1600 |
|---|---|---|---|
| Pallet Size | 1000mm x 1000mm | 1250mm x 1250mm | 1525mm x 1300mm |
| Table Index | Full 360° | Full 360° | Full 360° |
| X-Axis Travel | 1500mm | 1780mm | 2110mm |
| Y-Axis Travel | 1270mm | 1500mm | 1830mm |
| Z-Axis Travel | 1250mm | 1500mm | 1830mm |
| Max. Load on Pallet | 3,000kgs | 5,000kgs. | 8,000kgs |
| Spindles (2) | BBT50, 50Hp, 15,000 rpm | BBT50, 50 Hp, 15,000 rpm | BBT50, 60Hp, 12,000 rpm |
| X , Y, Z Rapid | 40m | 40m | 40m |
| Tool Storage | 60 Std, 90, 120, 180, 240 | 60 Std, 90 120, 180, 240 | 90 Std, 120, 180, 240 |
| Control * | Siemans ONE | Siemans ONE | Siemans ONE |
| Linear Position Accuracy | 0.005mm | 0.005mm | 0.005mm |
| Repeatability | 0.002mm | 0.002mm | 0.002mm |
| Rotary Table | 3 arc sec | 7 arc sec/3.5 arc sec | 7 arc sec/3.5 arc sec |
